Part no.: 08 2434 000 001
Snap-In Adapter, unshielded, VDE, Front mounting
Snap-In IP67, series 720, Miniature Connectors
General features
Moreless| Part no. | 08 2434 000 001 |
| Connector design | Adapter |
| Version | Adapter |
| Temperature range from/to | -25 °C / 85 °C |
| Weight (g) | 7.42 |
| Customs tariff number | 85366990 |
| Country of Origin | DE |
Electrical parameters
Moreless| Pollution degree | 2 |
| EMC compliance | unshielded |
Material
Moreless| Housing material | PA |
| REACH SVHC |
CAS 7439-92-1 (Lead) |
| SCIP number | 05a38a3d-094f-4305-a54e-1708a531137e |
Authorization/approvals
Moreless| Approvals | VDE |
Classifications
Moreless| eCl@ss 11.1 | 27-44-02-08 |
| ETIM 9.0 | EC002638 |
General Disclaim Notice
- The connector must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury.
- The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
- Connectors which are used in circuits with voltages dangerous to the touch may only be installed and used by, or under the supervision of, persons with electrical engineering training, taking into account the applicable regulations and standards.
- The user must take suitable safety precautions to ensure that the connector cannot be accidentally disconnected.
- Plug connectors with enclosure protection IP67 and IP68 are not suitable for use under water. When used outdoors, the plug connectors must be protected separately against corrosion. For further information on the IP protection classes, please refer to the "Technical Information" download centre.
- Please observe the pollution degree and the overvoltage category. For further information, please refer to the download center "Technical Information".
