  4. Bayonet Female cable connector, Contacts: 12, 7.0-13.0 mm, unshielded, crimping (Crimp contacts must be ordered separately), IP68/IP69K, UL, VDE
Part no.: 99 6518 000 12

Bayonet Female cable connector, Contacts: 12, 7.0-13.0 mm, unshielded, crimping (Crimp contacts must be ordered separately), IP68/IP69K, UL, VDE

Bayonet HEC, series 696, Power Connectors
Available numbers of contacts
Compare product
This female cable connector with bayonet locking system and a pin count of 12 is according to its protection class IP68/IP69K Dustproof and complete protection against contact. Protection against permanent submersion. Unless otherwise specified, protection up to 1 meter water depth. It can be used in areas with a pollution degree of 3. In places where contamination can occur that is conductive or can become conductive through condensation. With temperatures ranges of -40 °C/100 °C is this unshielded bayonet HEC female cable connector designed for both severe cold and severe heat and has the UL, VDE approval. Due to the qualified rated voltage of 250 V and the rated current of 5,0 A it is perfectly tuned for its field of application.
General features
Part no. 99 6518 000 12
Connector design Female cable connector
Version Connector socket straight
Connector locking system Bayonet
Termination crimping (Crimp contacts must be ordered separately)
Degree of protection IP68/IP69K
Cross-sectional area click here for more info
Cable outlet 7.0-13.0 mm
Temperature range from/to -40 °C / 100 °C
Mechanical operation > 500 Mating cycles
Weight (g) 60.10
Customs tariff number 85369010
Country of Origin DE
Rated voltage 250 V
Rated impulse voltage 4000 V
Rated current 5.0 A
Insulation resistance > 108 Ω
Pollution degree 3
Overvoltage category III
Insulating material group I
EMC compliance unshielded
Housing material PA
Contact body material PA
Contact material depending on crimp contact (accessory)
REACH SVHC None (No pollutants)
SCIP number SCIP-number not available
eCl@ss 11.1 27-44-01-02
ETIM 9.0 EC002635
Low Voltage Directive 2014/35/EU (EN 60204-1:2018;EN 60529:1991)
General Disclaim Notice
  1. The connector must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury.
  2. The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
  3. Connectors which are used in circuits with voltages dangerous to the touch may only be installed and used by, or under the supervision of, persons with electrical engineering training, taking into account the applicable regulations and standards.
