  4. Female cable connector, Contacts: 12, 5.5-8.6 mm, shieldable, solder, IP68/IP69K, UL, stainless steel
Part no.: 99 1492 992 12

Female cable connector, Contacts: 12, 5.5-8.6 mm, shieldable, solder, IP68/IP69K, UL, stainless steel

M12, series 713
Available numbers of contacts
Compare product
General features
Part no. 99 1492 992 12
Connector design Female cable connector
Type standard DIN EN 61076-2-101
Version Connector socket straight
Connector locking system screw
Termination solder
Degree of protection IP68/IP69K
Cross-sectional area max. 0.25 mm² / AWG 24
Cable outlet 5.5-8.6 mm
Temperature range from/to -40 °C / 85 °C
Mechanical operation > 500 Mating cycles
Additional information stainless steel
Weight (g) 55.52
Customs tariff number 85369010
Rated voltage 30 V
Rated impulse voltage 800 V
Rated current (40 °C) 1.5 A
Insulation resistance > 10⁸ Ω
Pollution degree 3
Overvoltage category II
Insulating material group III
EMC compliance shieldable
Shield connection Shielding ring
Housing material Stainless steel
Contact body material PA66 (UL94 HB)
Contact material CuSn (bronze)
Contact plating Au (gold)
Locking material Stainless steel
REACH SVHC CAS 7439-92-1 (Lead)
SCIP number a1709903-8a72-425d-a3ac-0d3f7674bf37
eCl@ss 11.1 27-44-01-02
ETIM 9.0 EC002635
General Disclaim Notice
  1. The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
  2. Plug connectors with enclosure protection IP67 and IP68 are not suitable for use under water. When used outdoors, the plug connectors must be protected separately against corrosion. For further information on the IP protection classes, please refer to the "Technical Information" download centre.
  3. To lock the cable connector with the device connector, the threaded ring is tightened "hand-tight" (approx. 60 cNm).
